Zen and the Art of Soldering in Electronics Manufacturing

Posted in EMS Solutions on by .
Soldering Electronics Manufacturing

Zen is an ancient Japanese word describing a sect of Buddhism that emphasizes the importance of meditation and self-reflection, in order to reach enlightenment. After these Buddhist concepts became popularized in the West, the word transformed into a modern meaning, often describing feelings of peacefulness, calmness, and serenity.

When you hear the word ‘Zen’ today, your mind probably does not conjure images of an electronics manufacturer. However, at ACDi, the art of dynamic electronics manufacturing brings us to a calm, focused, masterful state of mind. Through expertise and self-reflection, we’ve developed an artful process to electronics manufacturing that allows us to transform your concept into a functional product to bring to market.

Soldering is an Essential Tool in Manufacturing

One important aspect to the art of electronics manufacturing is soldering, the process of joining two or more metals together using molten filler metal. It’s an essential tool used in manufacturing, not just of electronics, but for countless products on the market today.

Usually comprised of tin and copper, solder is an alloy that melts at a lower temperature than the metal pieces to be joined. By heating and melting the solder, but not the components around it, it effectively bonds common components found in electronics manufacturing like resistors, transistors, capacitors, and LEDs, to a printed circuit board. Solder acts both as a structural glue, binding the component to the circuit board, as well as a conductor of electricity, allowing components on the board to work together harmoniously.

Artful Advantages of Soldering

Soldering can provide advantages where other forms of connection fall short. The benefit of soldering, as opposed to welding or brazing, is that the solder can always be heated again in order to move or change a component. It’s not permanently binding, giving engineers the freedom to adjust and perfect the printed circuit board layout. The art of circuit board layout isn’t always cut and dry, so having the freedom to test and move components can have both time and cost savings.

Soldering also creates a more reliable electrical connection, unlike cables that could easily become loose or disconnected. Each component serves a specific purpose, so in the event one becomes loose, the device may not work as intended, or even work at all. With soldering, the finished product will be more durable and user-friendly, which is an important feature to consumers.

In addition, there are unique benefits to different types of solder, depending on their alloy ratio, lead content, and water solubility. Alloy ratios effect the melting temperature, strength, physical appearance and a number of other factors, so it’s important to work with someone who fully understands the implications of these ratios. For example, lead-free solders are more expensive and often more difficult to work with, but are RoHS compliant, and can save costs later on.

Soldering for electronics manufacturing is a small, but crucial part of creating a functional device. It’s a simple tool with countless applications and many possible advantages. However, the complexity of the chemistry and the different types of solder available can create a web of potential outcomes. Working with a trusted, full-service electronics manufacturer, like ACDi, will ensure that you get the results you’re looking for. If you’d like to learn more about ACDi’s electronics manufacturing services, or receive a complementary consultation, give us a call at 301-363-4182, or reach out online. We look forward to hearing from you!
